Chieftain 2200

The Powerscreen® Chieftain 2200 2 Deck Screen is designed for operators who require large volumes of high specification products with maximum versatility. The Powerscreen Chieftain 2200 has two highly versatile double deck screenboxes which provide a total screening area of 19.5m2. It has a revolutionary patent pending drive system which allows switching between 2 and 4 bearing with bolt-on parts. The maximum variability of the Chieftain offers improved capabilities over its class rivals, especially in sticky scalping applications.

download brochure
Inquire Call us
Chieftain 2200
Chieftain 2200
Chieftain 2200
Chieftain 2200
Chieftain 2200
Chieftain 2200
Video Icon
Features & Benefits Options Specifications
  • High capacity up to 650 tph / 715 US tph (depending on media sizes & material type)
  • Maximum feed size 150mm (6’’)
  • Engine protection shutdown system
  • Power unit featuring a transverse engine arrangement to aid access & serviceability
  • Heavy duty double screenboxes with adjustable stroke, angle & speed
  • Fixed angle of 7° between screenboxes
  • Ability to easily change between 2 and 4 bearings using patent pending drive system
  • Hydraulic screen tensioning
  • Screen mesh access system for quicker mesh changes
  • Maximum mobility with heavy duty, low ground pressure tracks
  • Quick set up time
  • High performance hydraulic system – cast iron pumps & motors complete with hydraulic cooler
  • Low profile double deck vibrating grid option with radio remote control tipping grid, angle adjustable and fully riveted construction
  • Hydraulically folding conveyors for transport
  • Fines conveyor drop down facility to aid bottom deck mesh access
  • Powerscreen Pulse telemetry as standard
  • Double Deck Vibrating Grid
  • Target area: 3.91m (12’ 10”) long x 2.42m (7’ 11”) wide
  • Bottom deck screen size: 2 of 1.9m (6’ 3”) x 1.5m (4’ 11”)
  • Working angle:10º – 20º (hydraulically adjustable)
  • Tip angle: 45º max
  • Motor: 56cc/rev
  • Circuit: Coupled to main conveyor circuit
  • Dual Power System: 2 of electric motors 37 kW (50hp) & 37 kW (50hp) Diesel engine
  • Other options: custom colour machine, auto lubrication system, radio controlled tracking, low profile chevron on main conveyor belt, low profile chevron on tail conveyor belt, adjustable hopper door, fuel save option, quick release wedge tensioning for top deck, double deck vibrating grid, bottom deck self cleaning flexi mesh, vibrating grid discharge chute, crusher feed chute (when double deck vibrating grid is selected), hopper wear plates, grade 68 hydraulic oil, wear resistant lined spreader plate
  • Hopper capacity with tipping grid (rear): 6.9m³ (9 cu. yd.)
  • Hopper capacity without tipping grid (rear): 6.2m³ (8.1 cu. yd.)
  • Feed in height with grid: 3.7m (12’ 2”) (rear)
  • Feed in height without grid: 2.62m (8’ 7”) (rear)
  • 2 of 3.3 m x 1.55m (11’ x 5’) 2 deck incline screens
  • 3 of media sections (side tension) top deck per screenbox – 6 Total
  • 2 of media sections (end tension) bottom deck per screenbox – 4 Total
  • Finesize-Tail Conveyor: 4.7m (15’ 5’’) stockpile height
  • Feed Conveyor: 1200mm (48’’) wide feed conveyor with direct drive system & hydraulic variable speed control.
  • Main Conveyor: 1050mm (42”) 3 ply plain belt
  • Mid-Finesize & Mid-Oversize – Side Conveyors: 4.95m (16’ 2”) stockpile height
  • Tier 3 Equivalent: CAT C4.4 83 kW (111.3hp) @ 2200rpm
  • Tier 4F: CAT C3.6 82 kW (110hp) @ 2200rpm
  • Fuel tank: 336L (88 US Gal)
  • Total weight: 36,000kg (79,366lbs)
